1.25G WDM BiDi LC 10km SFP Transceiver 1310/1550nm compatible cisco/huawei/HP/Aruba/Ericsson/Mikrotik

Name: 1.25G WDM BiDi LC 10km SFP Transceiver 1310/1550nm compatible cisco/huawei/HP/Aruba/Ericsson/Mikrotik
Brand: UTOPTEK
SKU: UT-GE-BX10-L35
Rating: 4.5 (157 reviews)

Minimum Order Quantity :	2pcs	Packaging Details :	10pcs to one plastic plate
Delivery Time :	2-3days	Payment Terms :	T/T, Western Union,Paypal, Alipay,Wechat etc.
Supply Ability :	2000pcs per week

Place of Origin:	China	Brand Name:	UTOPTEK
Certification:	CE FCC RoHs	Model Number:	UT-GE-BX10-L35

Detail Information
Transmission Speed:	1.25Gb/s	Fiber Type:	Single-mode,Simplex LC
Distance:	10KM	DDM Function:	Support
Power Supply:	3.3V	Working Temperature:	0~70℃
Wavelength:	Tx1310/Rx1550	Warranty:	1 Year
Compatible:	Cisco,Huawei,HP,H3C,Juniper,Extreme Etc..

Product Description

1.25Gb/s 10Km LC BiDi SFP Transceiver

Hot Pluggable, Single LC, +3.3V, 1310nm Tx/1550nm Rx, FP-LD, Single-mode, DDM

UT-GE-BX10-L35

1.25G WDM BiDi LC 10km SFP Transceiver 1310/1550nm compatible cisco/huawei/HP/Aruba/Ericsson/Mikrotik 0

Description:

UTOPTEK’s UT-GE-BX10-L35 Transceivers are a high performance, cost effective module which have a single LC optics interface. They are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and Digital diagnostics functions are available via the 2-wire serial bus specified in SFF-8472. The receiver section uses a PIN receiver and the transmitter uses a 1310 nm FP laser, up to 14dB link budge ensure this module 1000Base-LX Ethernet 10km application.

Features:

Brand	UTOPTEK, OEM
Condition	100% New
Form Factor	SFP
Wavelength:	Tx1310nm/Rx1550nm
Distance	10KM
Data Rate (max)	1.25Gb/s
Working Temperature (°C)	0°C~70°C
Storage Temperature (°C)	-40°C~+85°C
Relative Humidity	0~85%
Voltage Supply	3.3--5v
Connector	LC
Warranty	1 year
Compatible with	Cisco, Haiwei, HP, etc.
Time of delivery	2-4 working days
Package	10 pcs/box

Applications:

1000Base-LX Ethernet
Metro/Access Networks
1×Fiber Channel
Other Optical Links

1.25G WDM BiDi LC 10km SFP Transceiver 1310/1550nm compatible cisco/huawei/HP/Aruba/Ericsson/Mikrotik 1

Ordering Information:

1.25G BIDI LC
UT-GE-BX03-L35	1.25G BIDI SMF Tx1310nm/Rx1550nm LC 3KM DDM 0-70℃
UT-GE-BX03-L53	1.25G BIDI SMF Tx1550nm/Rx1310nm LC 3KM DDM 0-70℃
UT-GE-BX10-L35	1.25G BIDI SMF Tx1310nm/Rx1550nm LC 10KM DDM 0-70℃
UT-GE-BX10-L53	1.25G BIDI SMF Tx1550nm/Rx1310nm LC 10KM DDM 0-70℃
UT-GE-BX20-L35	1.25G BIDI SMF Tx1310nm/Rx1550nm LC 20KM DDM 0-70℃
UT-GE-BX20-L53	1.25G BIDI SMF Tx1550nm/Rx1310nm LC 20KM DDM 0-70℃
UT-GE-BX20-L34	1.25G BIDI SMF Tx1310nm/Rx1490nm LC 20KM DDM 0-70℃
UT-GE-BX20-L43	1.25G BIDI SMF Tx1490nm/Rx1310nm LC 20KM DDM 0-70℃
UT-GE-BX40-L35	1.25G BIDI SMF Tx1310nm/Rx1550nm LC 40KM DDM 0-70℃
UT-GE-BX40-L53	1.25G BIDI SMF Tx1550nm/Rx1310nm LC 40KM DDM 0-70℃
UT-GE-BX40-L34	1.25G BIDI SMF Tx1310nm/Rx1490nm LC 40KM DDM 0-70℃
UT-GE-BX40-L43	1.25G BIDI SMF Tx1490nm/Rx1310nm LC 40KM DDM 0-70℃
UT-GE-BX40-L45	1.25G BIDI SMF Tx1490nm/Rx1550nm LC 40KM DDM 0-70℃
UT-GE-BX40-L54	1.25G BIDI SMF Tx1550nm/Rx1490nm LC 40KM DDM 0-70℃
UT-GE-BX60-L35	1.25G BIDI SMF Tx1310nm/Rx1550nm LC 60KM DDM 0-70℃
UT-GE-BX60-L53	1.25G BIDI SMF Tx1550nm/Rx1310nm LC 60KM DDM 0-70℃
UT-GE-BX60-L34	1.25G BIDI SMF Tx1310nm/Rx1490nm LC 60KM DDM 0-70℃
UT-GE-BX60-L43	1.25G BIDI SMF Tx1490nm/Rx1310nm LC 60KM DDM 0-70℃
UT-GE-BX60-L45	1.25G BIDI SMF Tx1490nm/Rx1550nm LC 60KM DDM 0-70℃
UT-GE-BX60-L54	1.25G BIDI SMF Tx1550nm/Rx1490nm LC 60KM DDM 0-70℃
UT-GE-BX80-L35	1.25G BIDI SMF Tx1310nm/Rx1550nm LC 80KM DDM 0-70℃
UT-GE-BX80-L53	1.25G BIDI SMF Tx1550nm/Rx1310nm LC 80KM DDM 0-70℃
UT-GE-BX80-L45	1.25G BIDI SMF Tx1490nm/Rx1550nm LC 80KM DDM 0-70℃
UT-GE-BX80-L54	1.25G BIDI SMF Tx1550nm/Rx1490nm LC 80KM DDM 0-70℃
UT-GE-BX100-L45	1.25G BIDI SMF Tx1490nm/Rx1550nm LC 100KM DDM 0-70℃
UT-GE-BX100-L54	1.25G BIDI SMF Tx1550nm/Rx1490nm LC 100KM DDM 0-70℃
UT-GE-BX120-L45	1.25G BIDI SMF Tx1490nm/Rx1550nm LC 120KM DDM 0-70℃
UT-GE-BX120-L54	1.25G BIDI SMF Tx1550nm/Rx1490nm LC 120KM DDM 0-70℃

1.25G WDM BiDi LC 10km SFP Transceiver 1310/1550nm compatible cisco/huawei/HP/Aruba/Ericsson/Mikrotik
