1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price

Name: 1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price
Brand: UTOPTEK
SKU: SFP-GE-CW20-xx
Rating: 4.6 (174 reviews)

Minimum Order Quantity :	2pcs	Packaging Details :	10pcs to one plastic plate
Delivery Time :	1-2days	Payment Terms :	T/T, Western Union,Paypal, Alipay,Wechat etc.
Supply Ability :	2000pcs per week

Place of Origin:	China	Brand Name:	UTOPTEK
Certification:	CE FCC RoHs	Model Number:	SFP-GE-CW20-xx

Detail Information
Transmission Speed:	1.25Gb/s	Fiber Type:	Duplex LC
Distance:	20Km	DDM Function:	Support
Power Supply:	3.3V	Working Temperature:	0~70℃
CWDM Wavelength:	1470nm~1610nm	Warranty:	3 Years
Compatible:	Cisco,Huawei,HP,H3C,Juniper,Extreme Etc..

Product Description

1.25Gb/s 20km CWDM SFP Transceiver

Hot Pluggable, Duplex LC, +3.3V, 1470nm～1610nm, CWDM DFB, Single-mode, DDM

Order Information:

In the Part No. of SFP-GE-CW20-xx, xx stands for central wavelength, such as:

47: for 1470nm, 49: for 1490nm, 51: for 1510nm……61: for 1610nm.

CWDM 1.25G SFP
SFP-GE-CW20-xx	1470 ~1610nm CWDM SFP+ 20km
SFP-GE-CW40-xx	1470 ~1610nm CWDM SFP+ 40km
SFP-GE-CW60-xx	1470 ~1610nm CWDM SFP+ 60km
SFP-GE-CW80-xx	1470 ~1610nm CWDM SFP+ 80km
SFP-GE-CW120-xx	1470 ~1610nm CWDM SFP+ 120km
SFP-GE-CW160-xx	1470 ~1610nm CWDM SFP+ 160km

Description:

UTOPTEK’s SFP-GE-CW20-xx series single mode transceiver is small form factor pluggable module for duplex optical data communications such as Gigabit Ethernet 1000BASE-ZX and Fiber Channel 1x SM-LC-L FC-PI. It is with the SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of CWDM wavelength. There are eighteen center wavelengths available from 1470nm to 1610nm, with each step 20nm.

The transmitter section uses a multiple quantum well CWDM DFB laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. The SFP-GE-CW20-xx series are designed to be compliant with SFF-8472.

Technical Specifications:

Brand	UTOPTEK, OEM
Condition	100% New
Form Factor	SFP CWDM
Wavelength:	1470nm~1610nm
Distance	20Km
Data Rate (max)	1.25Gb/s
Working Temperature (°C)	0°C~70°C
Storage Temperature (°C)	-40°C~+85°C
Relative Humidity	0~85%
Voltage Supply	3.3--5v
Power consuption	<1W
Connector	Duplex LC
Warranty	3 years
Compatible with	Cisco, Haiwei, HP etc.
Time of delivery	1-2 working days
Package	10 pcs/box

Features:

Data-rate of 1.25Gbps operation
18-Wavelength CWDM DFB LD Transmitter from 1470nm to 1610nm, with Step 20nm
Compliant with SFP MSA and SFF-8472
Compatible with SONET OC-24-LR-1
Compatible with RoHS
+3.3V single power supply
Hot-Pluggable SFP Footprint Duplex LC
Operating case temperature
Standard : 0°C to +70°C
Extended: -20°C to +85°C
Industrial: -40°C to +85°C

Applications:

Gigabit Ethernet
Fiber Channel Switch Infrastructure
Router/Server interface
Other optical transmission systems

Optical Parameters(T_OP =0 to 70°C, VCC = 3.135 to 3.465 Volts)

Parameter	Symbol	Min.	Typical	Max.	Unit	Note
Transmitter Section:
Center Wavelength	λ_c	λ-6	λ	λ+6.5	nm
Spectral Width(-20dB)	△λ			1	nm
Side Mode Suppression Ratio	SMSR	30			dB
Optical Output Power	P_out	-2		+3	dBm	1
Optical Rise/Fall Time	t_r / t_f			260	ps	2
Extinction Ratio	ER	8.2			dB
Eye Mask for Optical Output	Compliant with IEEE802.3z(class 1 laser safety)
Receiver Section:
Optical Input Wavelength	λ_c	1260		1620	nm
Receiver Overload	P_ol	-8			dBm	3
RX Sensitivity	Sen			-24	dBm	3
RX_LOS Assert	LOS_A	-40			dBm
RX_LOS De-assert	LOS_D			-25	dBm
RX_LOS Hysteresis	LOS _H	0.5			dB
General Specifications:
Data Rate	BR		1.063/1.25		Gb/s
Bit Error Rate	BER			10^-12
Max. Supported Link Length on 9/125μm SMF@1.25Gb/s	L_MAX		40		km
Total System Budget	LB	21			dB

Mechanical Dimensions:

1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price 0

1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price 1

Compatible Testing:

1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price 2

Components:

1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price 4

1.25G CWDM SFP 20km-160km 1470nm~1610nm fiber optical transceiver module best price 5
