10G XFP SR MM Duplex LC 850nm 300meter DDM Cisco Compatible XFP optical module

Name: 10G XFP SR MM Duplex LC 850nm 300meter DDM Cisco Compatible XFP optical module
Brand: UTOPTEK
SKU: XFP-10G-SR
Rating: 4.9 (130 reviews)

Minimum Order Quantity :	2pcs	Packaging Details :	10pcs to one plastic plate
Delivery Time :	1-2days	Payment Terms :	T/T, Western Union,Paypal, Alipay,Wechat etc.
Supply Ability :	2000pcs per week

Place of Origin:	China	Brand Name:	UTOPTEK
Certification:	CE FCC RoHs	Model Number:	XFP-10G-SR

Detail Information
Transmission Speed:	10Gb/s	Fiber Type:	Multi-mode,Duplex LC
Distance:	300Meters	DDM Function:	Support
Power Supply:	3.3V	Working Temperature:	0~70℃
Wavelength:	TRX850nm	Warranty:	3 Years
Compatible:	Cisco,Huawei,HP,H3C,Juniper,Extreme Etc..

Product Description

10Gb/s 300m XFP Transceiver

Hot Pluggable,Duplex LC,+3.3V, 850nm VCSEL,Multi Mode

Description:

The XFP-10G-SR small Form Factor 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. The high performance uncooled 850nm Vcsel transmitter and high sensitivity PIN receiver provide superior performance for 10G Fibre Channel and Ethernet applications up to 300m optical links.

Features:

Support multi protocol from 9.95Gb/s to 11.3Gb/s
Hot-Pluggable 30 pin connector
Compliant with XFP MSA
Transmission distance of 300m over multi mode fiber
850nm VCSEL laser transmitter
Duplex LC connector
2-wire interface for management and diagnostic monitor
XFI electrical interface with AC coupling
Single power supply voltages : +3.3V
Temperature range 0°C to 70°C
Power dissipation: <1.5W
RoHS Compliant Part

Brand	UTOPTEK, OEM
Condition	100% New
Form Factor	XFP
Wavelength:	TRx850nm
Distance	300Meters
Data Rate (max)	10Gb/s
Working Temperature (°C)	0°C~70°C
Storage Temperature (°C)	-40°C~+85°C
Relative Humidity	0~85%
Voltage Supply	3.3--5v
Power consuption	<1.5W
Connector	Duplex LC
Warranty	3 years
Compatible with	Cisco, Haiwei, HP etc.
Time of delivery	1-2 working days
Package	10 pcs/box

Factory Show:

10G XFP SR MM Duplex LC 850nm 300meter DDM Cisco Compatible XFP optical module 3

Ordering Information:

Part No.	Data Rate	Form Factor	Distance	Wavelength	Transmitter	Receiver	Interface	Temp.
XFP-10G-SR	10Gb/s	XFP	300m	850nm	VCSEL	PIN	LC	0-70℃
XFP-10G-LR 10km	10Gb/s	XFP	10km	1310nm	DFB	PIN	LC	0-70℃
XFP-10G-LR	10Gb/s	XFP	20km	1310nm	DFB	PIN	LC	0-70℃
XFP-10G-ER	10Gb/s	XFP	40km	1550nm	EML	PIN	LC	0-70℃
XFP-10G-ZR	10Gb/s	XFP	80km	1550nm	EML	APD	LC	0-70℃
XFP-10G-ZR 100km	10Gb/s	XFP	100km	1550nm	EML	APD	LC	0-70℃

XFP-10G-BX20-L27	10Gb/s	BiDi XFP	20km	Tx1270/Rx1330nm	DFB	PIN	LC	0-70℃
XFP-10G-BX20-L33	10Gb/s	BiDi XFP	20km	Tx1330/Rx1270nm	DFB	PIN	LC	0-70℃
XFP-10G-BX40-L27	10Gb/s	BiDi XFP	40km	Tx1270/Rx1330nm	DFB	PIN	LC	0-70℃
XFP-10G-BX40-L33	10Gb/s	BiDi XFP	40km	Tx1330/Rx1270nm	DFB	PIN	LC	0-70℃
XFP-10G-BX60-L27	10Gb/s	BiDi XFP	60km	Tx1270/Rx1330nm	DFB	APD	LC	0-70℃
XFP-10G-BX60-L33	10Gb/s	BiDi XFP	60km	Tx1330/Rx1270nm	DFB	APD	LC	0-70℃

XFP-10G-CW10-xx	10Gb/s	CWDM XFP	10km	1270~1330nm	DFB	PIN	LC	0-70℃
XFP-10G-CW10-xx	10Gb/s	CWDM XFP	10km	1350~1450nm	DFB	PIN	LC	0-70℃
XFP-10G-CW20-xx	10Gb/s	CWDM XFP	20km	1270~1330nm	DFB	PIN	LC	0-70℃
XFP-10G-CW40-xx	10Gb/s	CWDM XFP	40km	1470~1610nm	EML	PIN	LC	0-70℃
XFP-10G-CW80-xx	10Gb/s	CWDM XFP	80km	1470~1550nm	EML	APD	LC	0-70℃

XFP-10G-DW40-CHxx	10Gb/s	DWDM SFP+	40km	1528.77~1563.86nm	EML	PIN	LC	0-70℃
XFP-10G-DW80-CHxx	10Gb/s	DWDM SFP+	80km	1528.77~1563.86nm	EML	APD	LC	0-70℃
XFP-10G-DW100-CHxx	10Gb/s	DWDM SFP+	100km	1528.77~1563.86nm	EML	APD	LC	0-70℃

10G XFP SR MM Duplex LC 850nm 300meter DDM Cisco Compatible XFP optical module
