10G Bidi LC 80km 1490/1550nm Fiber optical 10G 80km sfp transceiver module for cisco/huawei

Minimum Order Quantity :	2pcs	Packaging Details :	10pcs to one plastic plate
Delivery Time :	1-2days	Payment Terms :	T/T, Western Union,Paypal, Alipay,Wechat etc.
Supply Ability :	2000pcs per month

Place of Origin:	China	Brand Name:	UTOPTEK
Certification:	CE FCC RoHs	Model Number:	SFP-10G-BX80-L49/55

Detail Information
Transmission Speed:	10Gb/s	Fiber Type:	Single-mode,Single LC
Distance:	80km	DDM Function:	Support
Power Supply:	3.3V	Working Temperature:	0~70℃
Wavelength:	Tx1490nm/Rx1550nm	Warranty:	3 Years
Compatible:	Cisco,Huawei,HP,H3C,Juniper,Extreme Etc..

Product Description

10Gb/s 80km SFP+ Transceiver Hot Pluggable, Single LC, +3.3V, 1490nm/1550nm DFB, DDM
SFP-10G-BX80-L49 (Tx1490nm/Rx1550nm)
SFP-10G-BX80-L55 (Tx1550nm/Rx1490nm)

Features:

●Supports 9.95 to 11.3Gb/s bit rates

●Simplex LC Connector

●Hot pluggable SFP+ footprint

●Cooled 1490nm EML transmitter, 1550nm APD receiver

●Cooled 1550nm EML transmitter, 1490nm APD receiver

●Applicable for 80km SMF connection

●Low power consumption, < 1.5W

●Digital Diagnostic Monitor Interface

●Optical interface compliant to IEEE 802.3ae 10GBASE-ZR

●Electrical interface compliant to SFF-8431

●Operating case temperature:

Commerical:0 to 70 °C

Brand	UTOPTEK, OEM
Condition	100% New
Form Factor	SFP+
Wavelength:	Tx1490nm/Rx1550nm
Distance	80KM
Data Rate (max)	10Gb/s
Working Temperature (°C)	0°C~70°C
Storage Temperature (°C)	-40°C~+85°C
Relative Humidity	0~85%
Voltage Supply	3.3--5v
Power consuption	<1.5W
Connector	Simplex LC
Warranty	3 years
Compatible with	Cisco, Haiwei, HP etc.
Time of delivery	1-2 working days
Package	10 pcs/box

Factory Show:

10G Bidi LC 80km 1490/1550nm Fiber optical 10G 80km sfp transceiver module for cisco/huawei 0

10G Bidi LC 80km 1490/1550nm Fiber optical 10G 80km sfp transceiver module for cisco/huawei 3

Ordering Information:

10Gbps SFP+ Transceiver
Part No.	Data Rate	Form Factor	Distance	Wavelength	Transmitter	Receiver	Interface	Temp.
SFP-10G-SR	10Gb/s	SFP+	300m	850nm	VCSEL	PIN	LC	0-70℃
SFP-10G-LR10	10Gb/s	SFP+	10km	1310nm	DFB	PIN	LC	0-70℃
SFP-10G-LR	10Gb/s	SFP+	20km	1310nm	DFB	PIN	LC	0-70℃
SFP-10G-ERM	10Gb/s	SFP+	40km	1310nm	DFB	APD	LC	0-70℃
SFP-10G-ER	10Gb/s	SFP+	40km	1550nm	EML	PIN	LC	0-70℃
SFP-10G-ZR	10Gb/s	SFP+	60km	1550nm	EML	APD	LC	0-70℃
SFP-10G-ZR	10Gb/s	SFP+	80km	1550nm	EML	APD	LC	0-70℃
SFP-10G-ZR100	10Gb/s	SFP+	100km	1550nm	EML	APD	LC	0-70℃

SFP-10G-BX20-L27	10Gb/s	BiDi SFP+	20km	Tx1270/Rx1330nm	DFB	PIN	LC	0-70℃
SFP-10G-BX20-L33	10Gb/s	BiDi SFP+	20km	Tx1330/Rx1270nm	DFB	PIN	LC	0-70℃
SFP-10G-BX40-L27	10Gb/s	BiDi SFP+	40km	Tx1270/Rx1330nm	DFB	PIN	LC	0-70℃
SFP-10G-BX40-L33	10Gb/s	BiDi SFP+	40km	Tx1330/Rx1270nm	DFB	PIN	LC	0-70℃
SFP-10G-BX60-L27	10Gb/s	BiDi SFP+	60km	Tx1270/Rx1330nm	DFB	APD	LC	0-70℃
SFP-10G-BX60-L33	10Gb/s	BiDi SFP+	60km	Tx1330/Rx1270nm	DFB	APD	LC	0-70℃
SFP-10G-BX80-L49	10Gb/s	BiDi SFP+	80km	Tx1490/Rx1550nm	EML	APD	LC	0-70℃
SFP-10G-BX80-L55	10Gb/s	BiDi SFP+	80km	Tx1550/Rx1490nm	EML	APD	LC	0-70℃
SFP-10G-BX80-L49	10Gb/s	BiDi SFP+	80km	Tx1490/Rx1570nm	EML	APD	LC	0-70℃
SFP-10G-BX80-L57	10Gb/s	BiDi SFP+	80km	Tx1570/Rx1490nm	EML	APD	LC	0-70℃
SFP-10G-BX100-L49	10Gb/s	BiDi SFP+	100km	Tx1490/Rx1550nm	EML	APD	LC	0-70℃
SFP-10G-BX100-L55	10Gb/s	BiDi SFP+	100km	Tx1550/Rx1490nm	EML	APD	LC	0-70℃

SFP+10G-CW10-xx	10Gb/s	CWDM SFP+	10km	1270~1610nm	DFB	PIN	LC	0-70℃
SFP+10G-CW20-xx	10Gb/s	CWDM SFP+	20km	1270~1370nm	DFB	PIN	LC	0-70℃
SFP+10G-CW20-xx	10Gb/s	CWDM SFP+	20km	1470~1570nm	DFB	PIN	LC	0-70℃
SFP+10G-CW20-xx	10Gb/s	CWDM SFP+	20km	1570~1610nm	DFB	PIN	LC	0-70℃
SFP+10G-CW40-xx	10Gb/s	CWDM SFP+	40km	1270~1610nm	DFB	PIN	LC	0-70℃
SFP+10G-CW40-xx	10Gb/s	CWDM SFP+	40km	1470~1610nm	EML	PIN	LC	0-70℃
SFP+10G-CW80-xx	10Gb/s	CWDM SFP+	80km	1470~1610nm	EML	APD	LC	0-70℃
SFP+10G-CW100-xx	10Gb/s	CWDM SFP+	100km	1470~1550nm	EML	APD	LC	0-70℃

SFP+10G-DW40-CHxx	10Gb/s	DWDM SFP+	40km	1528.77~1563.86nm	EML	PIN	LC	0-70℃
SFP+10G-DW80-CHxx	10Gb/s	DWDM SFP+	80km	1528.77~1563.86nm	EML	APD	LC	0-70℃
SFP+10G-DW100-CHxx	10Gb/s	DWDM SFP+	100km	1528.77~1563.86nm	EML	APD	LC	0-70℃
